The Medicaid CardioMax-6Cm is a 3-channel digital ECG machine designed for quick and clear 12-lead ECG recording and analysis. It supports simultaneous 12-lead acquisition, real-time waveform display, automatic and manual analysis, internal ECG record storage, and built-in thermal printing. With AC/DC power operation, a rechargeable Li-ion battery, and USB connectivity, the CardioMax-6Cm is suitable for routine ECG workflows in clinics, hospitals, and diagnostic settings.
Product Overview
The CardioMax-6Cm combines 3-channel ECG recording with simultaneous acquisition of all 12 ECG leads. Its high-resolution colour TFT display provides real-time waveform visualization, while automatic analysis and interpretation features help streamline routine ECG examinations.
The machine can store up to 200 ECG records internally and includes a built-in thermal printer for producing ECG printouts. It also supports 3-lead rhythm printing on 100 mm paper.
✅ Key Features
- 3-channel ECG recording with interpretation
- Simultaneous 12-lead ECG acquisition
- Real-time ECG waveform display
- High-resolution colour TFT display
- Automatic and manual analysis modes
- Internal memory for up to 200 ECG records
- Built-in thermal printer
- 3-lead rhythm printing
- 100 mm recording paper
- Built-in rechargeable Li-ion battery
- AC/DC power operation
- USB interface for data transfer
12-Lead Simultaneous ECG Acquisition
The CardioMax-6Cm supports simultaneous acquisition of all 12 ECG leads, enabling efficient recording of standard 12-lead ECG examinations.
Although it is a 3-channel ECG recorder, the system acquires the 12-lead ECG configuration for examination and analysis.
Colour TFT Display
The machine features a high-resolution colour TFT display for real-time visualization of ECG waveforms. This allows the operator to monitor the acquired signals during the ECG examination.
Automatic & Manual Analysis
The CardioMax-6Cm provides two operating/analysis modes:
-
Automatic mode for streamlined ECG recording and analysis
-
Manual mode for operator-controlled ECG recording
This provides flexibility for different clinical ECG workflows.
Internal ECG Memory
The device can store up to 200 ECG records in its internal memory. Stored examinations can help facilitate ECG record management and review.
Built-In Thermal Printer
The CardioMax-6Cm includes an integrated thermal printer for ECG documentation.
Printing specifications
-
Printer: Built-in thermal printer
-
Rhythm printing: 3-lead
-
Recording paper: 100 mm
Rechargeable Battery
The ECG machine is equipped with a built-in rechargeable Li-ion battery, allowing operation without continuous connection to AC power.
It also supports AC/DC power operation, providing flexibility for clinical use.
USB Connectivity
A USB interface is provided for data transfer and connectivity with compatible systems.
Technical Specifications
| Specification |
Details |
| Brand |
Medicaid |
| Model |
CardioMax-6Cm |
| Device Type |
3-Channel ECG Machine |
| Lead Acquisition |
12-lead simultaneous |
| ECG Recording |
3-channel |
| Operating Mode |
Automatic / Manual |
| Analysis |
Automatic / Manual |
| Display |
High-resolution Colour TFT |
| Printer |
Built-in thermal printer |
| Rhythm Printing |
3-lead |
| Recording Paper |
100 mm |
| Internal Memory |
Up to 200 ECG records |
| Connectivity |
USB interface |
| Battery |
Built-in rechargeable Li-ion battery |
| Power Operation |
AC / DC |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
