The Arkray AutoChem Ingenious Semi-Automated Clinical Chemistry Analyzer is designed for clinical laboratories that require reliable biochemical testing, flexible assay methods, and integrated coagulation testing. This compact laboratory analyzer combines photometry, coagulation analysis, and incubation in a single system, helping reduce the need for separate equipment.
With storage for up to 144 test parameters and a patient database supporting 2,000 samples, the Arkray AutoChem Ingenious is suitable for small and medium-sized diagnostic laboratories seeking a compact, versatile semi-automated chemistry analyzer.
Key Features of Arkray AutoChem Ingenious
-
Three-in-one functionality: Combines photometry, coagulation testing, and incubation.
-
Multiple assay methods: Supports end-point, kinetic, fixed-time, and coagulation modes.
-
Flexible calibration: Offers factor, single-standard, and multi-standard calibration with spline or point-to-point options.
-
Built-in incubation: Features a 16-tube incubation block operating at 37°C ±0.2°C.
-
Peltier-based temperature control: Supports controlled cuvette temperatures at 30°C and 37°C.
-
Real-time absorbance curves: Displays absorbance curves to assist with result monitoring.
-
Patient data management: Stores data for up to 2,000 samples.
-
Test parameter storage: Stores up to 144 test parameters.
-
Convenient printing: Includes an internal thermal printer and supports an external dot matrix printer.
-
Flexible input: Uses a 28-key membrane keypad with optional external keyboard support.
-
Compact design: Measures 35 × 34 × 26 cm and weighs less than 10 kg.
Test Menu and Assay Capabilities
The Arkray AutoChem Ingenious supports a range of clinical laboratory assay methods, including:
-
Clinical chemistry assays
-
Immunoturbidimetric tests
-
End-point tests with or without sample blank
-
Kinetic tests with or without reagent blank
-
Fixed-time assays
-
Coagulation assays
Technical Specifications
| Specification |
Details |
| Analyzer type |
Semi-automated clinical chemistry analyzer |
| Optical system |
Single beam with rotating filter wheel |
| Measurement |
Monochromatic and biochromatic |
| Light source |
Quartz halogen lamp, 12 V, 20 W |
| Standard wavelengths |
340, 405, 510, 546, 578, 630 nm |
| Optional wavelengths |
2 optional filters |
| Calculation modes |
Absorbance, end point, kinetic, fixed time, coagulation |
| Calibration modes |
Factor, single standard, multi-standard |
| Multi-standard calibration |
6 points, spline or point-to-point |
| Cuvette temperature control |
Peltier-based |
| Operating temperatures |
30°C and 37°C ±0.2°C |
| Incubation block |
16 tubes, 37°C ±0.2°C |
| Pump |
Stepper-driven peristaltic pump |
| Display |
240 × 128 graphical LCD |
| Input |
28-key membrane keypad; optional external keyboard |
| Output |
Real-time absorbance curve, internal thermal printer |
| External printer support |
Dot matrix printer |
| Connectivity |
Serial port |
| Power supply |
90–260 VAC |
| Power consumption |
100 W |
| Dimensions |
35 cm (W) × 34 cm (D) × 26 cm (H) |
| Weight |
Less than 10 kg |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
