The BPL H-RAD 32 Fixed X-Ray Machine (DR-1 variant) is a digital radiography system designed for comprehensive whole-body X-ray imaging in hospitals, diagnostic centres, and radiology departments. Equipped with a 32 kW POSKOM high-frequency X-ray generator, a rotating-anode Canon X-ray tube, and a large-format 17 × 17-inch CsI flat panel detector, the system supports a wide range of general radiography examinations.
The system features a floor-to-ceiling tube stand and a ceiling-free detector stand, providing flexibility for routine radiographic positioning. Its advanced Image Stitching software combines multiple exposures into a single, seamless long-spine or long-leg image, helping simplify extended-length imaging workflows without manual detector repositioning.
Key Features of the BPL H-RAD 32 X-Ray Machine
-
32 kW High-Frequency Generator: Powered by a 50 kHz POSKOM generator for general radiography applications.
-
Wide Exposure Range: Supports tube voltage from 40 to 125 kVp and tube current from 10 to 400 mA.
-
17 × 17-Inch Flat Panel Detector: Features a CsI-based amorphous silicon detector with a 9.4-megapixel resolution.
-
Advanced Image Stitching: Combines multiple exposures into a single image for full-spine and long-leg studies.
-
Floor-to-Ceiling Tube Stand: Provides flexible tube positioning with 360° tube rotation.
-
LED Collimator: High-brightness imported LED collimator supports positioning of the X-ray field.
-
Ceiling-Free Detector Stand: Supports detector positioning for general radiography, including chest imaging at a 180 cm source-to-image distance (SID).
-
216 Anatomical Programs: Includes configurable anatomical programs for different examination protocols.
-
PACS and DICOM Connectivity: Supports integration with digital radiology workflows, CD/DVD burning, and USB data export.
-
Self-Diagnostic Error Indication: Helps identify system errors for troubleshooting.
-
Optional E-Console Workstation: Provides real-time and post-processing capabilities when included in the selected configuration.
Technical Specifications
| Specification |
Details |
| Brand |
BPL |
| Model |
H-RAD 32 |
| Variant |
DR-1 |
| Equipment Type |
Fixed digital X-ray machine |
| Generator Output |
32 kW |
| Generator Frequency |
50 kHz |
| Tube Voltage Range |
40–125 kVp |
| kVp Adjustment |
1 kV per step |
| Tube Current Range |
10–400 mA |
| Maximum mAs |
Up to 630 mAs |
| X-Ray Tube |
Rotating anode, Canon |
| Small Focal Spot |
1.0 × 1.0 mm |
| Large Focal Spot |
2.0 × 2.0 mm |
| Anatomical Programs |
216, user configurable |
| Detector Type |
CsI–a-Si flat panel detector |
| Detector Size |
17 × 17 inches |
| Detector Resolution |
3072 × 3072 pixels |
| Detector Resolution in Megapixels |
Approximately 9.4 MP |
| Pixel Pitch |
140 µm |
| A/D Conversion |
14-bit |
| AED |
Lossless AED, as specified |
| Tube Stand |
Floor-to-ceiling column |
| Tube Stand Height |
2400–3300 mm |
| Tube Rotation |
360° |
| X-Ray Table |
Mobilio mobile table |
| Floating Tabletop |
Optional |
| Image Stitching |
Supported for full-spine and long-leg imaging |
| Connectivity |
PACS, DICOM, CD/DVD burning and USB export |
| Optional Workstation |
E-Console workstation |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
