The Erba Chem 7 is a compact, semi-automated clinical chemistry analyzer designed for small- to mid-sized diagnostic laboratories and hospitals. It supports routine clinical chemistry, electrolyte analysis, immunoturbidimetric assays, and coagulation tests.
The Erba Chem 7 clinical chemistry analyzer features a static photometer with an eight-filter optical system, a triple cuvette system, Peltier temperature control, multiple analysis modes, built-in quality control functions, and patient test result storage. Its interface includes a backlit graphical LCD, 56 direct-access keys, a high-resolution thermal printer, and USB connectivity.
Key Features of Erba Chem 7
-
Compact, semi-automated clinical chemistry analyzer
-
Designed for small- to mid-sized diagnostic laboratories and hospitals
-
Supports clinical chemistry, electrolytes, immunoturbidimetric assays, and coagulation tests
-
Memory for up to 1,000 test results
-
Built-in three-level quality control and Levy-Jennings plots
-
USB ports for PC or external printer connection
Technical Specifications
| Specification |
Details |
| Product Name |
Erba Chem 7 |
| Product Type |
Semi-Automated Clinical Chemistry Analyzer |
| Optical System |
Static photometer |
| Filter Wheel |
8 interference filters |
| Standard Wavelengths |
340, 405, 450, 505, 546, 578, 600, 670 nm |
| Light Source |
12V/20W quartz halogen lamp |
| Temperature Control |
Peltier-controlled |
| Temperature Range |
20°C–40°C |
| Test Result Memory |
Up to 1,000 results |
| Quality Control |
Built-in 3-level QC and Levy-Jennings plots |
| Display |
Backlit graphical LCD |
| Keyboard |
56 direct-access keys |
| Printer |
Built-in high-resolution thermal printer |
| Connectivity |
USB ports for PC or external printer connection |
| Weight |
Approximately 7 kg |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
