The JMJ Medical Durlax Plus Anesthesia Workstation is a high-performance anesthesia delivery system designed for hospital operating theatres, surgical centres, and critical-care environments. It combines controlled anesthetic gas delivery with an integrated anesthesia ventilator, touchscreen operation, multiple ventilation modes, and essential safety alarms.
The workstation features a 7-inch touchscreen display and supports Volume Control (VC), Pressure Control (PC), and SIMV ventilation modes, providing flexibility for different surgical and patient requirements. Its tidal volume range of 50–1500 mL and adjustable respiratory frequency of 6–40 breaths/min support controlled mechanical ventilation.
A 5-tube rotameter system provides separate flow control for 2 Oxygen, 2 Nitrous Oxide, and 1 Air. The Durlax Plus supports semi-open, semi-closed, and closed breathing systems and includes oxygen flush, oxygen-failure alarm, pressure alarms, and reverse-flow protection.
The workstation is built with a durable, rust-resistant fiber body and is mounted on antistatic castor wheels with front brakes for convenient movement within the OT. Two sliding drawers provide practical storage for anesthesia accessories.
Key Features
- Integrated anesthesia ventilator
- 7-inch touchscreen display
- VC, PC, and SIMV ventilation modes
- Tidal volume: 50–1500 mL
- Respiratory frequency: 6–40 bpm
- 5-tube rotameter system
- 2 × Oxygen, 2 × Nitrous Oxide, 1 × Air flowmeters
- Supports two vaporizer mounting positions
- Oxygen flush: 35–75 L/min
- High- and low-pressure alarms
- Oxygen/source failure alarm
- Reverse-flow protection safety valve
- Semi-open, semi-closed, and closed breathing systems
- Cylinder and pipeline gas connections
- Antistatic castor wheels with front brakes
- Two sliding storage drawers
- Durable rust-resistant fiber body
Ventilation Modes
- Volume Control (VC)
- Pressure Control (PC)
- SIMV (Synchronized Intermittent Mandatory Ventilation)
Technical Specifications
| Specification |
Details |
| Brand |
JMJ Medical |
| Model |
Durlax Plus |
| Product Type |
Anesthesia Workstation |
| Display |
7-inch Touchscreen |
| Ventilation Modes |
VC, PC, SIMV |
| Tidal Volume |
50–1500 mL |
| Respiratory Frequency |
6–40 bpm |
| I:E Ratio |
1:4 to 4:1* |
| PIP |
10–60 cmH₂O |
| Flowmeter |
5-Tube Rotameter |
| Flowmeter Configuration |
2 O₂, 2 N₂O, 1 Air |
| O₂ Flush |
35–75 L/min |
| Breathing System |
Semi-open / Semi-closed / Closed |
| Cylinder Attachment |
2 O₂ + 2 N₂O |
| Pipeline Attachment |
2 O₂ + 1 N₂O + 1 Air |
| Power Supply |
AC 220V |
| Alarms |
High Pressure, Low Pressure, Source/Oxygen Failure |
| Safety Valve |
Reverse-Flow Protection |
| Vaporizers |
Provision for 2 Vaporizers |
| Mobility |
Antistatic Castor Wheels |
| Brakes |
Front Wheel Brakes |
*Exact displayed I:E range may vary according to the supplied configuration.
Benefits
- Integrated ventilator simplifies anesthesia workstation setup
- Multiple ventilation modes provide greater clinical flexibility
- Wide tidal-volume range supports different patient requirements
- Five-tube flowmeter enables O₂, N₂O, and Air delivery
- Multiple safety alarms enhance monitoring during anesthesia
- Durable construction is suitable for regular hospital use
- Wheels and brakes provide convenient OT mobility
- Storage drawers keep essential accessories organized
Applications
- Hospital Operating Theatres
- General Surgery
- Surgical Centres
- Anesthesia Departments
- Critical Care Departments
- Medical Centres
- Procedures requiring controlled ventilation
- General anesthesia administration
What's Included
- JMJ Medical Durlax Plus Anesthesia Workstation
- Integrated anesthesia ventilator
- 5-tube gas-flow rotameter assembly
- O₂ and N₂O cylinder yoke system
- Vaporizer mounting platform
- Breathing circuit connection system
- Trolley base with wheels and brakes
- Storage drawers and accessory space
