Maestros Vital Wave Biphasic Defibrillator | Portable Biphasic Defibrillator
Product Selection • Best Price • Technical Support
The Maestros Vital Wave Biphasic Defibrillator is a high-performance emergency cardiac care device designed to deliver fast, safe, and effective defibrillation for patients experiencing life-threatening cardiac arrhythmias such as Ventricular Fibrillation (VF) and Pulseless Ventricular Tachycardia (VT). Engineered for hospitals, emergency departments, ICUs, ambulances, and critical care units, this portable biphasic defibrillator combines advanced monitoring capabilities with rapid energy delivery to improve patient outcomes during cardiac emergencies.
Featuring biphasic waveform technology, a 7-inch high-resolution TFT color display, ECG monitoring, event trend storage, and optional SpO₂ and NIBP upgrades, the Vital Wave provides clinicians with reliable performance when every second matters. Its lightweight design, intuitive controls, and rechargeable battery make it an ideal solution for both bedside and emergency transport applications.
At Health Yantra Store, we offer genuine Maestros medical equipment backed by manufacturer warranty for dependable quality and after-sales support.
Key Features
Advanced Biphasic Defibrillation
Delivers controlled biphasic shocks up to 270 Joules, improving defibrillation success while reducing myocardial stress compared to conventional monophasic systems.
High-Resolution 7-inch TFT Display
Bright 800 × 480 color TFT screen displays ECG waveforms, heart rate, selected energy level, and patient monitoring information clearly, even in emergency environments.
Fast Charging Performance
Charges to the maximum 270 Joules in less than 8 seconds, minimizing treatment delays during cardiac emergencies.
Long Battery Backup
Rechargeable lithium-polymer battery delivers over 50 defibrillation shocks or more than 3 hours of continuous ECG monitoring on a single charge.
Flexible ECG Monitoring
Supports ECG acquisition through both patient cables and defibrillator paddles, providing flexibility during emergency and bedside monitoring.
Event Trend Storage
Stores up to 24 hours of patient event data, enabling clinicians to review treatment history and patient progress.
Expandable Monitoring Options
Upgradeable with SpO₂ and Non-Invasive Blood Pressure (NIBP) modules for comprehensive patient monitoring.
Reliable Alarm & Monitoring System
Provides accurate ECG monitoring with selectable gain settings, multiple sweep speeds, and high signal clarity for dependable cardiac assessment.
Benefits of the Maestros Vital Wave Biphasic Defibrillator
- Provides rapid defibrillation during sudden cardiac arrest emergencies.
- Biphasic waveform technology improves treatment effectiveness while minimizing cardiac tissue damage.
- Ideal for emergency rooms, ICUs, ambulances, operating theatres, and critical care units.
- Large TFT display enables easy patient monitoring and treatment visualization.
- Portable design allows convenient bedside and transport use.
- Event memory supports patient documentation and clinical review.
- Optional SpO₂ and NIBP monitoring expand patient assessment capabilities.
- Durable construction ensures dependable performance in demanding clinical environments.
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | Maestros Vital Wave Biphasic Defibrillator |
| Defibrillation Type | Biphasic |
| Maximum Energy | 270 Joules |
| Display | 7-inch TFT Color Display (800 × 480 Pixels) |
| ECG Channels | 2 Channel |
| ECG Leads | 3/5 Lead Configuration |
| ECG Acquisition | Patient Cable & Paddles |
| Displayed Waveforms | 2 Waveforms |
| Heart Rate Range | 30–240 bpm |
| Heart Rate Accuracy | ±2 bpm |
| Gain Settings | 5, 10, 15, 20 mm/mV |
| Sweep Speed | 12.5 / 25 / 50 mm/sec |
| Frequency Response | 0.05–40 Hz |
| CMRR | >100 dB |
| Input Impedance | >100 MΩ |
| Recorder | High-Resolution Thermal Array Printer |
| Battery | 14.8V, 4400 mAh Li-Polymer |
| Battery Backup | 40–50 Shocks or 3+ Hours Monitoring |
| Charging Time | Approx. 8 Hours |
| Data Storage | Up to 24 Hours Event Trend Storage |
| Upgradeable Options | SpO₂ & NIBP |
Box Contents
Your package includes:
- Maestros Vital Wave Biphasic Defibrillator
- Adult Defibrillation Electrodes
- Rechargeable Battery
- AC Power Adapter & Power Cord
- Carrying Case
- User Manual
- Data Transfer Cable (where applicable)
Warranty
The Maestros Vital Wave Biphasic Defibrillator comes with a 1-year manufacturer warranty, ensuring dependable performance and reliable service support.
