The Refurbished Medtronic Capnostream 35 Portable Respiratory Monitor is a lightweight and rugged respiratory monitoring device designed for continuous observation of a patient's respiratory status across a variety of clinical environments.
The Medtronic Capnostream 35 combines Microstream capnography with Nellcor pulse oximetry to monitor key respiratory and oxygenation parameters, including end-tidal carbon dioxide (EtCO₂), SpO₂, respiration rate, and pulse rate.
A major feature of the monitor is its Integrated Pulmonary Index (IPI), which combines EtCO₂, SpO₂, respiration rate, and pulse rate into a single index ranging from 1 to 10. This provides an integrated view of the patient's respiratory condition.
Designed for portability, the monitor weighs approximately 1 kg (2.2 lbs) and is described as shockproof from heights of up to 1.25 meters. Its hot-swappable battery capability supports continued monitoring, with the supplied information indicating approximately 3 hours of operation for the removable battery pack.
The Capnostream 35 Portable Respiratory Monitor features a 4.3-inch color touchscreen, advanced alarm-management functions, and connectivity options including wireless connectivity through the Vital Sync platform and local data export through USB/microSD.
The dedicated EMS Mode is optimized for emergency and resuscitation scenarios, allowing monitoring to begin quickly.
As a refurbished medical device, the exact configuration, accessories, battery condition, software, sensor compatibility, and functional status should be verified before procurement and clinical use.
✅ Key Features
- ✅ Refurbished Medtronic Capnostream 35 Portable Respiratory Monitor
- ✅ Lightweight & Rugged Respiratory Monitor
- ✅ Approximately 1 kg / 2.2 lbs
- ✅ Microstream Capnography
- ✅ Nellcor Pulse Oximetry
- ✅ EtCO₂ Monitoring
- ✅ SpO₂ Monitoring
- ✅ Respiration Rate Monitoring
- ✅ 4.3-Inch Color Touchscreen
- ✅ Approximately 3 Hours Removable Battery Operation
- ✅ Wireless Connectivity via Vital Sync on Supported Configurations
- ✅ USB / microSD Data Export
- ✅ Dedicated EMS Mode
- ✅ Suitable for Emergency & Resuscitation Monitoring
- ✅ Portable Respiratory Monitoring Solution
- ✅ Cost-Effective Refurbished Medical Equipment
Microstream Capnography
The Capnostream 35 uses Microstream capnography technology to monitor end-tidal carbon dioxide (EtCO₂) and respiratory information.
EtCO₂ monitoring provides respiratory information that can be used alongside other monitored parameters for comprehensive respiratory observation.
Nellcor Pulse Oximetry
The monitor integrates Nellcor pulse oximetry for SpO₂ and pulse-rate monitoring.
Combining SpO₂ with capnography allows the Medtronic Capnostream 35 to provide multiple respiratory and oxygenation measurements through one portable monitoring platform.
Integrated Pulmonary Index (IPI)
The Integrated Pulmonary Index (IPI) is one of the key monitoring features of the Capnostream 35.
IPI combines four monitored parameters:
- EtCO₂
- SpO₂
- Respiration Rate
- Pulse Rate
The resulting index is presented on a scale from 1 to 10, providing an integrated indicator based on these respiratory and oxygenation measurements.
Portability & Rugged Construction
The Medtronic Capnostream 35 is designed for portable clinical use.
Supplied portability specifications:
- Weight: approximately 1 kg / 2.2 lbs
- Shockproof capability: up to approximately 1.25 meters
- Portable form factor
- Hot-swappable battery capability
These characteristics make it suitable for environments where respiratory monitoring may need to continue while moving or transporting patients.
EMS Mode
The EMS Mode is designed specifically for emergency medical services and resuscitation scenarios.
According to the supplied information, the default EMS mode is optimized to allow the monitor to move directly into monitoring, supporting rapid setup during emergency situations.
Technical Specifications
| Specification |
Details |
| Product Name |
Medtronic Capnostream 35 Portable Respiratory Monitor |
| Brand |
Medtronic |
| Model |
Capnostream 35 |
| Condition |
Refurbished |
| Device Type |
Portable Respiratory Monitor |
| Capnography |
Microstream |
| Pulse Oximetry |
Nellcor |
| EtCO₂ |
Yes |
| SpO₂ |
Yes |
| Respiration Rate |
Yes |
| Pulse Rate |
Yes |
| Integrated Pulmonary Index |
IPI |
| IPI Range |
1–10 |
| Display |
4.3-Inch Color Touchscreen |
| Weight |
Approx. 1 kg / 2.2 lbs |
| Shock Resistance |
Up to Approx. 1.25 m |
| Battery |
Removable / Hot-Swappable Capability |
| Battery Runtime |
Approx. 3 Hours for Removable Pack |
| Wireless Connectivity |
Vital Sync on Supported Configurations |
| Data Export |
USB / microSD |
| Emergency Mode |
EMS Mode |
| Primary Application |
Respiratory & Oxygenation Monitoring |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
