The ZOLL M2 Monitor/Defibrillator is a portable, rugged monitor-defibrillator designed for adult and pediatric resuscitation, emergency transport, and hospital care.
The system combines ZOLL Rectilinear Biphasic™ defibrillation, manual defibrillation, semi-automatic AED operation, synchronized cardioversion, non-invasive transcutaneous pacing, advanced patient monitoring, and real-time CPR feedback.
With scalable monitoring capabilities including ECG, SpO₂, NIBP, EtCO₂ and temperature, the ZOLL M2 is designed to support clinicians from initial emergency response through ongoing patient monitoring and transport.
Key Features
-
ZOLL Rectilinear Biphasic™ defibrillation technology
-
Energy delivery up to 200J
- High-current optimization for high-impedance patients
- Manual defibrillation
- Semi-automatic AED mode
- Specialized pediatric AED algorithms
- Synchronized cardioversion
- Constant-current non-invasive transcutaneous pacing
- 40 ms pacing waveform
-
Real CPR Help™ real-time CPR feedback
-
Live CPR Dashboard
- ECG monitoring in 3-, 5- or 12-lead configurations
- Heart rate monitoring
- Impedance pneumography
- SpO₂ pulse oximetry
- NIBP monitoring
- EtCO₂ capnography
- Dual-channel temperature monitoring
- High-contrast color LCD
- Built-in high-resolution thermal recorder/printer
- USB data transfer
- 802.11 Wi-Fi connectivity
-
Compatibility with RescueNet CaseReview
- Rechargeable/replaceable lithium-ion battery
- Up to 4 hours of monitoring or over 100 maximum-energy shocks
- External paddles with built-in pediatric electrodes
- Universal multifunction cable
-
Approximately 6.5 kg including battery and paper
-
IP44 durability rating
- 0.75-meter drop-test certification
ZOLL Rectilinear Biphasic™ Defibrillation
The ZOLL M2 uses ZOLL Rectilinear Biphasic™ technology for defibrillation.
The supplied specifications identify:
-
Maximum energy: 200J
- High-current optimization
- Designed to address high patient impedance
- Biphasic defibrillation waveform
The device supports professional manual defibrillation as well as semi-automatic AED operation.
Manual Defibrillation & AED
Manual Defibrillation
The ZOLL M2 provides manual defibrillation for trained healthcare professionals, allowing clinical teams to manage emergency cardiac resuscitation according to applicable protocols.
Non-Invasive Transcutaneous Pacing
The ZOLL M2 incorporates constant-current non-invasive transcutaneous pacing for emergency management of bradycardia.
The supplied specifications identify a:
- Constant-current pacing system
- 40 ms waveform
- Non-invasive transcutaneous operation
Real CPR Help™ & CPR Dashboard
A major feature of the ZOLL M2 is its integrated CPR feedback technology.
Real CPR Help™
Real CPR Help™ provides real-time audio and visual guidance regarding:
- CPR rate
- Compression depth
This helps clinicians receive immediate feedback during chest compressions.
CPR Dashboard
The live CPR Dashboard provides a dedicated view of CPR performance information during resuscitation.
Patient Monitoring
The ZOLL M2 provides scalable monitoring capabilities for emergency and hospital care.
ECG
Supported ECG configurations include:
Heart Rate
Heart rate monitoring is supported as part of the ECG monitoring system.
Impedance Pneumography
The M2 supports respiration monitoring using impedance pneumography.
SpO₂
The system supports pulse oximetry (SpO₂) monitoring.
NIBP
Non-invasive blood pressure monitoring is available.
EtCO₂
Capnography provides end-tidal carbon dioxide (EtCO₂) monitoring.
Temperature
The supplied specifications identify 2-channel temperature monitoring.
Display & User Interface
The ZOLL M2 incorporates a high-contrast color LCD designed for emergency clinical use.
The interface provides access to:
- Patient waveforms
- Vital-sign information
- Defibrillation controls
- Pacing functions
- CPR feedback
- Alarm and monitoring information
The supplied specifications do not provide the exact display size or resolution, so these details have not been added.
Battery & Power
The ZOLL M2 supports both AC mains operation and rechargeable battery operation.
Battery
The supplied specifications identify a:
-
Rechargeable/replaceable Lithium-ion battery
-
Up to 4 hours of monitoring
-
More than 100 maximum-energy shocks
Actual battery performance can vary according to monitoring configuration, therapeutic use and battery condition.
Data Management & Connectivity
The ZOLL M2 includes several options for clinical documentation and data transfer.
USB
A USB data-transfer port is included.
Wi-Fi
The device supports 802.11 Wi-Fi connectivity and is compatible with RescueNet CaseReview.
This enables supported clinical data to be transferred for review and documentation.
Paddles, Cables & Accessories
The supplied typical configuration includes:
- External paddle assembly
- Built-in pediatric electrodes
- Universal multifunction cable
- 3-lead patient cable
- AC power cord
- Protective carry case
- Rechargeable/replaceable lithium-ion battery
- Thermal recorder paper
Exact accessories may vary according to the selected configuration.
Rugged & Portable Design
The ZOLL M2 is designed for demanding emergency environments.
Technical Specifications
| Specification |
ZOLL M2 Monitor/Defibrillator |
| Brand |
ZOLL Medical |
| Device Type |
Portable Monitor/Defibrillator |
| Patient Population |
Adult & Pediatric |
| Defibrillation Technology |
ZOLL Rectilinear Biphasic™ |
| Maximum Defibrillation Energy |
Up to 200J |
| Manual Defibrillation |
Yes |
| Semi-Automatic AED |
Yes |
| Pediatric AED Algorithms |
Yes |
| Synchronized Cardioversion |
Yes |
| Transcutaneous Pacing |
Yes |
| Pacing Type |
Constant-current |
| Pacing Waveform |
40 ms |
| CPR Feedback |
Real CPR Help™ |
| CPR Dashboard |
Yes |
| ECG |
3-, 5-, or 12-lead |
| Heart Rate |
Yes |
| Respiration |
Impedance Pneumography |
| SpO₂ |
Yes |
| NIBP |
Yes |
| EtCO₂ |
Yes |
| Temperature |
2 channels |
| Display |
High-contrast color LCD |
| Recorder |
Built-in high-resolution thermal printer |
| Data Transfer |
USB |
| Wireless |
802.11 Wi-Fi |
| Software/Data Compatibility |
RescueNet CaseReview |
| Battery |
Rechargeable/replaceable Lithium-ion |
| Monitoring Runtime |
Up to 4 hours |
| Shock Capacity |
Over 100 maximum-energy shocks |
| Weight |
Approx. 6.5 kg including battery & paper |
| Protection |
IP44 |
| Drop Test |
0.75 m |
| Paddles |
External paddles with built-in pediatric electrodes |
Product Disclaimer
Specifications and included accessories may vary by production batch, market, or manufacturer revision. Please verify the exact configuration with the seller before purchase. This product information is intended for general product guidance and does not replace professional medical advice, diagnosis, or treatment.
